BEP Marine 3-Position Touch Control IP66 Rated 24V Black 2-Way DIN Rail Mount Push Button Switch
Product details
| Management number | 247531452 | Release Date | 2026/08/16 | List Price | US$7.28 | Model Number | 247531452 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Single pole, double throw switch turns one of two circuits on. Common applications include intermittent manual override and maintained float switch bilge pump control. Includes one Amber LED
- Contura switches are rated to Ip66, high-pressure wash resistant. Recommended for replacements in waterproof electrical panels with rocker switches to ensure waterproof integrity
- Nominal voltage 12V/24V DC. Rated for 20a at 12V DC, 15a at 24V DC
- 1/4" blade terminals. Snap-in mounting to fit panel Hole 1.45" x .83" into panels .093" to .187" thick
- Replaces Cole hersee part number 58332-23
| UPC | 870216046440 |
|---|---|
| ASIN | B07B6TQ6V7 |
| Color | 1 Amber LED |
| Model | 1001805 |
| Terminal | Spdt |
| Brand Name | BEP |
| Unit Count | 1 Count |
| Item Weight | 1.28 ounces |
| Part Number | 1001805 |
| Switch Type | Rocker |
| Circuit Type | 2-way |
| Contact Type | Normally Open |
| Manufacturer | Marinco Electrical Group |
| Actuator Type | Plunger |
| Material Type | Plastic |
| Mounting Type | Pole |
| Connector Type | Clamp |
| Current Rating | 20 A |
| Item Type Name | SPDT Contura Switch, One LED -On/Off/(On) |
| Operation Mode | ON-OFF |
| Item Dimensions | 2 x 1.2 x 2 inches |
| Number of Items | 1 |
| Contact Material | Brass |
| Operating Voltage | 12 volts |
| Specification Met | Ip66 |
| Included Components | Contura Switches: 12V & 24V |
| Number of Positions | 2 |
| Warranty Description | Warranty |
| Connectivity Protocol | X-10 |
| Lower Temperature Rating | 40 °C |
| Upper Temperature Rating | 85 °C |
| International Protection Rating | IP66 |
| Global Trade Identification Number | 00870216046440 |
