HDM66 HD Modulator, AV RF Modulator Support PAL NTSC TV Format Output, 1080P PLL Control of VHF Operating Frequency, for Local CATV System Home HDMI TV

Specification: Item Type: HD Modulator Product Model: HDM66 Product Material: ABS TV Standard: PAL, NTSC Frequency Range: PAL: 55.25MHz/62.25MHz; NTSC: 61.25MHz/67.25MHz Output Level: 80±5dBuV Sound System: M=4.5MHz, B=5.5MHz Input Port: HD Multimedia Interface Output Port: AV Female RF Input: F Female RF Output: F Female Input Resolution: 1080P/1080i/720P/576P/576i/480p HD Multimedia Version: 1.3 HDCP Version: 1.3 Input Voltage: 5V 500mA How to Use: Installation Steps 1: Connect the USB output power adapter; 2: Channel is set to CH3 or CH4, modulator is set to ON; (Set to OFF, RF does not work); 3: Connect RF input and RF output; 4: Open the HD multimedia device power supply, connect the input signal; 5: Turn on the TV to CH3 or CH4. Please follow the above steps strictly Package List: 1 x Modulator 1 x Supply Cord 1 x User Manual

• Support PAL NTSC Format: The high definition modulator supports both NTSC and PAL TV format outputs, with strong compatibility, making it versatile for use with your local CATV system
• Plug and Play: With no driver required, this HD modulator offers convenience and flexibility, and ease of use, simply plug it in and start enjoying your high definition content, convenient and practical
• Frequency Range: With 55.25MHz / 62.25MHz PAL, 61.25MHz / 67.25MHz NTSC frequency range, this high definition modulator is suitable for home HD multimedia TV, has a wide range of application
• 1080P PLL Control: Boasting 1080P PLL control VHF working frequency, the HD modulator supports HD input with AV and RF output options, delivering exceptional picture quality and clarity
• ABS Housing: Made from ABS material, this HD input modulator is built to last, offering a long service life, stability, and high reliability for professional and home entertainment applications
